eWON4001™
Installation Guide
ver 2.1
page 22 of 31
8 Technical support
If you need technical support, simply fill out the form on the Web site http://www.ewon.biz or send an email with the
problem description to support@ewon.biz
.
9 Appendix: Pinouts and connections
9.1 Power Supply
Figure 10: eWON Mating female connector (included)
• Manufacturer:
Phoenix Contact GmbH, http://www.phoenixcontact.com
Part Number: GMSTB 2,5/2-STF-7,62
• Pinout
(see label)
Pin Description
1 Ground
2 Positive (+)
Table 15: Pinout Power Supply Connector
