eWON4001™
Installation Guide
ver 2.1
page 5 of 31
3 Housing and markings
3.1 Housing Interfaces
Figure 1: Housing, front view
Figure 2: Housing, bottom view
Leds
Ethernet port
10/100 Base Tx
Phone line
Reset button
Configurable
serial port
DIN rail latch
Digital I/O
Power supply
12-24 VDC
