eWON4001™
Installation Guide
ver 2.1
page 6 of 31
3.2 Markings
The identification label of the eWON is placed at the left hand side of the housing. The label is composed of the
following fields: The label layout has slightly evolved since the product ws launched.
Figure 3: eWON Labels
Serial number
0645 = year+week
0003 = sequential number
66 = suffix eWON4001MPI/ETH
88 = suffix eWON4001/ETH
89 = suffix eWON4002/ETH
Type name + COM type
../PSTN56 = modem 56k
../GPRS = GSM modem GPRS comp.
Required power supply
The power supply must be limited to
max 300mA and be SELV-compliant
(safety voltage)
Earlier style label
Later style label
Serial number
1247 = year+week
0001 = sequential number
66 = suffix eWON4001MPI/ETH V1
88 = suffix eWON4001/ETH V1
89 = suffix eWON4002/ETH V1
91 = suffix eWON4001/ETH V2
Part Number
Part Number as per Price List.
Required power supply
The power supply must be limited to
max 300mA and be SELV-compliant
(safety voltage)
Options + HW Version
In the case of V2 HW it is mentioned
here (V1 is NOT mentioned).
