eWON4001™

Installation Guide

ver 2.1

page 25 of 31

9.2.2 Connection over hub/router

If the eWON is connected to a hub, it has to be connected like any other device, with a straight cable. Again, the

wiring is as shown on the following picture, and care should be taken to keep the RX and TX signals on twisted

pairs:

Hub/Router

Straight

cable
