ACT Recommend the Epson LQ-300:
Wiring between Printer & Controller: Controller Printer
0v TX RX SERIAL (25 way connector)
0V ............................PIN 7
TX............................PIN 3
RX ..........................PIN 20
Printer settings:
CHARACTER TABLE PC850 PAGE LENGTH OF TRACTOR 11 INCHES
SKIP OVER PERFORATION OFF AUTO TEAR OFF OFF
GRAPHIC PRINT DIRECTION BI-D SOFTWARE ESC/P2
AGM OFF AUTO LINE FEED OFF
INTERFACE SERIAL DATA LENGTH 8 BITS
BIT RATE 9600BPS EXT/ACK OFF
PARITY BIT NONE STATE REPLY OFF
FILTER LOG
The Filter Log function allows the user to prevent certain events from being entered on the system
log. Normally all events are logged, but to prevent ACTWin pro from having to store a lot of
information on a large installation, some events may be filtered out.
The event types that can be filtered are access granted, access denied, alarms (mains fail, tamper
etc.), door events (exit button pressed etc.) and others. The 0 key advances to each event, and the
✔ key enables or disables the displayed event type.
The events may also be filtered out on certain doors. Normally all doors are allowed, but the user
may prevent certain doors from reporting events.
ACTpro 3000 Operating Instructions Firmware Version 1.24
8
Control Door
The Control Door menu allows the operator to control the door or externally connected equipment
such as lighting or heating.
LOCK DOOR
The Lock Door function causes the door relay to be de-energized. The bottom line of the display
will show “Door Locked” and the red LED on the reader will flash. All subsequent cards will be
rejected until the door is unlocked or returned to its normal state.
UNLOCK DOOR
The Unlock Door function causes the door relay to be energized. The bottom line of the display
will show “Door Unlocked” and the green LED on the reader will flash.
NORMALISE DOOR
The Normalise Door function causes the door relay to be de-energized and the door to return to
its normal state. The LED on the reader stops flashing and all subsequent operation will be the
normal response to card activity.
PASS DOOR
The Pass Door function causes the door relay to be energized for the programmed period of time.
This may be used to grant access to a person waiting outside the door.
