Burst/Fast transient
EN 61000-4-4
2kV for power supply
lines
2kV for power supply
lines
Quality of the Main power source should be that
of a typical commercial or hospital environment
Surge
EN 61000-4-5
1kV differential mode
2kV common mode
1kV differential mode
2kV common mode
Quality of the Main power source should be that
of a typical commercial or hospital environment
Voltage dips, short
interruptions and
voltage variation on
power supply input
lines.
EN 61100-4-11
5%Ut
(  95% dip in U
t
) for 0,5 cycle
40% Ut
(60% dip in U
v
) for 5 cycle
70% U
t
(30% dip in U
t
) per 25 cycle
5% U
t
(  95% dip in U
t
) for 5 sec
5%Ut
(  95% dip in U
t
) for 0,5 cycle
40% Ut
(60% dip in U
v
) for 5 cycle
70% U
t
(30% dip in U
t
) per 25 cycle
5% U
t
(  95% dip in U
t
) for 5 sec
Quality of the Main power source should be that
of a typical commercial or hospital environment If
the user of the I-SURGE requires continued
operation during power main interruptions, it is
recommended than the I-SURGE be powered from
an uninterruptible power supply or battery.
Power frequency
(50/60 Hz)
magnetic field
EN 61100-4-8
3A/m
3A/m
Power frequency magnetic fields should be at a
typical commercial or hospital establishment
level.
