Installation Guide
5
2. Install the gang box converter onto the gang box using the screws included in the gang box
package. Note which screw holes to attach to secure the converter to the gang box.
Screw Holes from Left to Right
Screw Holes from Right to Left
NOTE: Same screw holes apply when using the 4” round gang boxes.
Installed gang box converter example is shown below.
