Waterproof Solution with Conduit
This section describes the procedures to waterproof the cabling connections using the bundled
conduit gland and flexible conduit. This is the recommended if an exterior-grade Ethernet cable is
not available or when other cables, such as DI/DO devices, etc., will be connected to the camera.
1. Prepare the following materials for waterproof installation:
Conduit Gland
(included in the camera package)
Flexible Conduit
1/2" Trade size
(not included in the package)
For use with 1/2” flexible conduit
Network Cable
CAT 5 or CAT 6
(not included in the package)
