Step 2: Mount the Camera
1. Slide the camera through the flush mount.
2. Attach the set screw to one of the holes on top of the flush mount to fix the depth of the
lens position.
Meanwhile, the final installation on the other side of the surface will only show the
camera lens. Example image below:
