13. Technical Specifications
13.1. Electrical Specifications
SYMBOL PARAMETER CONDITIONS MIN TYPICAL MAX UNITS
POWER SUPPLY INTERFACES
POWER SUPPLY INPUT
VSS DC supply voltage - 11 24 30 V
ISS DC supply load current
VSS=24V - - 10 A
VSS=14V - - 10 A
ISS
STBY
DC supply standby load
current
ACC=0V - - 30 mA
ANTENNA POWER OUTPUT
Vo DC output voltage
Output enabled 11.8 12 12.3 V
Output disabled - 0 - V
Io DC output current Output enabled - - 300 mA
RELAY POWER OUTPUT
Vo DC output voltage
VSS=24V
Output enabled
- 0 - V
VSS=24V
Output disabled
- Z - V
Io DC output current
VSS=24V
Output enabled
- - 200 mA
USB POWER OUTPUT
Vo DC output voltage - - 5 - V
Io DC output current - - - 1.2 A
INPUTS
MICROPHONE INPUT
Vin Input peak voltage
f=1kHz
Zo=600R
- 5.5 - mVp
Zin Output impedance - 2 - - kohm
BW Bandwidth A=±3dB 200 - 4000 Hz
