SYMBOL PARAMETER CONDITIONS MIN TYPICAL MAX UNITS
STEREO AUDIO INPUT (AUDIO LINE-IN)
Vin Input peak-to-peak voltage
f=1kHz
Zo=600R
- - 3.3 Vpp
Zin Output impedance - - 27 - kohm
BW Bandwidth A=±3dB 20 - 20000 Hz
OUTPUTS
STEREO AUDIO OUTPUT (AUDIO LINE-OUT)
Vo Output rms voltage
f=1kHz
Zin=10Kohm
- 0.5 0.7 VRMS
Zo Output impedance - - - 600 ohm
BW Bandwidth A=±3dB 20 - 20000 Hz
SNR Signal Noise Ratio
f=1kHz
Zin=10Kohm
80 - - dB
THD Total Harmonic Distortion
f=1kHz
Zin=10Kohm
- - 0.5 %
RADIO STEREO AUDIO OUTPUT (RADIO LINE-OUT)
Vo Output rms voltage
f=1kHz
Zin=10Kohm
- 0.5 0.7 VRMS
Zo Output impedance - - - 600 ohm
BW Bandwidth A=±3dB 300 - 15000 Hz
SNR Signal Noise Ratio
f=1kHz
Zin=10Kohm
80 - - dB
THD Total Harmonic Distortion
f=1kHz
Zin=10Kohm
- - 0.5 %
SPEAKER OUTPUTS (POWER AUDIO OUTPUT)
ZL Speaker load VSS=28V 4 - - ohm
Po Output RMS power
f=1kHz
ZL=4ohm
THD=1%
VSS=28V
- 15 - W
f=1kHz
ZL=4ohm
THD=10%
VSS=28V
- 20 - W
f=1kHz
ZL=4ohm
THD=10%
VSS=14V
- 10 - W
