SYMBOL PARAMETER CONDITIONS MIN TYPICAL MAX UNITS
XT Crosstalk between channels
f=1kHz
ZL=4ohm
THD=1%
VSS=28V
60 - - dB
BW Bandwidth A=±3dB 20 - 20000 Hz
VIDEO INTERFACES
CBVS VIDEO OUTPUT
Vo Output peak-to-peak voltage Zin=75ohm - - 1 Vpp
Zo Output impedance - - 75 - ohm
Hres Horizontal resolution
NTSC - 480 - lines
PAL - 576 - lines
SNR Signal Noise Ratio Zin=75ohm 60 - - dB
CBVS VIDEO INPUT
Vin Output peak-to-peak voltage Zo=75ohm 0.8 - 1.2 Vpp
Zin Output impedance - - 75 - ohm
Hres Horizontal resolution
NTSC - 480 - lines
PAL - 576 - lines
DIGITAL INTERFACES
ACC AND DIMMING INPUTS
VIH High level input voltage State=input active 11 - 32 V
VIL Low level input voltage State=input inactive 0 - 7.5 V
Iin Leakage Current State=input active - - 5 mA
MUTE INPUT
VIH High level input voltage State=input inactive 11 - 32 V
VIL Low level input voltage State=input active 0 - 0.6 V
Iin Input Leakage Current State=input inactive - - 5 mA
13.2. Mechanical Specifications
PARAMETER VALUE
Installation Size (W x H x D) 182 mm x 53 mm x 160 mm
Maximum weight 1.2 kg
