8
Assembly Instructions
5. Assembly Instructions (cont.)
5.4 Assembly (cont.)
4 5
Attach high-pressure hose to the gun and
the pump outlet (hand tighten only, do not
use any tape to secure connections). Ensure
the hose adapter to the pressure washer
pump outlet is a m22-15mm connection!
Attach the desired spray tip to the wand. The
spray tips are for the following purposes:
• 0° For tough spots and grimes (e.g., concrete
surfaces).
• 15° For medium and heavy duty cleaning tasks
(e.g.driveway).
• 40° For light duty jobs and to apply detergent
(e.g., stucco walls, glossy surfaces).
0º
15º
40º
