Installation and Commissioning Guide
Split Ducted ESP Digital
Installation and Commissioning Guide - Split Ducted ESP Digital Units
Doc. No.0525-077 Ver. 2 200129
15
07.06. SRD233C
UNIT MODEL
NUMBER
UNIT
WEIGHT
(kg)
CORNER WEIGHTS (kg)
A
B C D
LM RM
SRD233C 225 19.6 72.3 29.5 82.9 7.9 12.8
OVERALL NOMINAL DIMENSION H X W X L
= 1105 X 1685 X 685
PLEASE NOTE THAT UNDER ALL CIRCUMSTANCES,
CONDENSER AIR MUST NOT RECIRCULATE BACK ONTO
CONDENSER COIL. KEEP ALL CLEARANCES FREE OF
ANY OBSTRUCTIONS
671
(MTG C-C DIST)
553112
118
59
1105
O/A
670
437
118
58
533
(MTG C-C DIST)
60
1685 O/A
380
565
685
O/A
COMP
OUTDOOR COIL
OUTDOOR
AIR INLET
OUTDOOR
AIR INLET
OUTDOOR
AIR INLET
295
125
1025
50
616
(MTG C-C DIST)
GAS PIPE
28.6 mm (1-1/8")
ELECT. ACCESS
2 x 25.4 mm (1")
LIQUID PIPE
12.7 mm (1/2") SWAGED
210.5
(MTG C-C DIST)
283
36.5
FRONT VIEW
SIDE VIEW
TOP VIEW
A
B
C
D
600 mm
SERVICE / AIRFLOW CLEARANCE
NIL - TO - MINIMUM SERVICE CLEARANCE
300 mm
SERVICE / AIRFLOW
CLEARANCE
673.5
(MTG C-C DIST)
555.5
25
25
110
118
59
59
OUTDOOR
AIR OUTLET
OUTDOOR
AIR INLET
1025
1685 O/A
380 565
685
O/A
COMP
OUTDOOR COIL
OUTDOOR
AIR INLET
1105
O/A
50
295
670
555.5
118 118
110
673.5
(MTG C-C DIST)
60
30
616
(MTG C-C DIST)
125
GAS PIPE
28.6 mm (1-1/8")
LIQUID PIPE
15.9 mm (5/8")
SWAGED
ELECT. ACCESS
2 x 25.4 mm (1")
OUTDOOR
AIR INLET
OUTDOOR
AIR INLET
800 mm
SERVICE
CLEARANCE
(COMPRESSOR
AND
ELECTRICALS)
OUTDOOR COIL
COMP
MINIMUM SERVICE ACCESS AREAS
AND AIRFLOW CLEARANCES
HEIGHT CLEARANCE
= 1500 mm
NOTES:
1. Do not scale drawing. All dimensions are in mm unless specified. Refer
to corresponding unit dimensional drawing for mounting hole details.
2. Service Access Areas and Spaces for Airflow Clearances given above are
suggested minimum based on the condition that the spaces around the
units are free from any obstructions and a walkway passage of 1000mm
between the units or between the unit and the outside perimeter is
available.
3. Minimum service access areas and spaces for airflow clearances are
responsibilities of the installer, ActronAir will not be held liable for any
extra charges incurred due to lack of access and space for airflow.
4. Under all circumstances, condenser air must not recirculate back onto
condenser coil. Keep all clearance free of any obstructions.
5. Maximum External Static of Outdoor Fans is 5 Pa.
6. STACKING OF UNITS: Ensure that minimum airflow and clearances are
met.
7. Refer to Pipe Connection Details on Specifications Sheet.
8. MTG C-C DIST = Mounting Centre to Centre Distance.
9. Use M12 bolt for feet mounting.
THIRD ANGLE
PROJECTION
