10
5-in-1 Sensor Setup
Set the A-B-C Switch
Locate the A-B-C switch inside the
battery compartment. It can be
set to A, B or C. However, you
must select the same letter choices
for the display, 5-in-1 sensor and
lightning sensor in order for the
units to synchronize.
Install or Replace Batteries
Batteries MUST be installed for
this product to operate. AcuRite
recommends high quality alkaline
or lithium batteries for the best
product performance. Heavy duty
or rechargeable batteries are not
recommended.
The 5-in-1 sensor requires lithium
batteries in low temperature
conditions. Cold temperatures can
cause alkaline batteries to function
improperly. Use lithium batteries in
the 5-in-1 sensor for temperatures
below -4ºF/-20ºC.
1. Slide off the battery
compartment cover.
2. Insert 4 x AA batteries into the
battery compartment, as
shown. Follow the polarity
(+/-) diagram in the battery
compartment.
3. Replace the battery cover.
Remove Rain Gauge Stabilizer
Locate and remove the rain gauge
stabilizer (plastic tab) taped into
the bottom of the sensor. The rain
gauge will not function until this is
removed.
2
3
1
A B C
1
A-B-C Switch
Set to match
display &
lightning sensor
2
Install Batteries
4 AA Batteries
3
Rain Gauge Stabilizer
Remove and discard
NOTE: If add-on sensors are being used with the display (see page 17), set them up at this
time. If pairing more than one wireless sensor with the display, the A-B-C channel must differ
between each add-on sensor. The display will automatically begin searching for add-on sensors
during initial setup.
