The tachometer shows the engine
speed in revolutions per minute
(rpm). To protect the engine from
damage, never drive with the
tachometer needle in the red zone.
This shows your speed in kilometers
per hour (km/h).
The odometer shows the total
number of kilometers your vehicle
has been driven. The total number is
displayed when you turn the ignition
switch ON (II).
Speedometer
Odometer
Tachometer
Gauges
Instruments and Controls
74
TACHOMETER
TRIP METER
ODOMETER
TRIP METER RESET BUTTON
TRIP METER
SELECT BUTTON
TEMPERATURE
GAUGE
FUEL GAUGESPEEDOMETER
02/12/03 17:40:57 32S3V800_079
