ADA MP-1 Owner’s manual
NOTES ON ADA SYSTEM EXCLUSIVE MESSAGES
1. All messages include a 7 bit 2's complement checksum taken over all the data
bytes (does"' include the SYSEX. EOX. or checksum itself).
2. Values are in “Humber" format (MS bits sent first):
Byte 1 0 0
6 bit value
Byte 1 0 1 0 0 0 0 0 1
7 bit value
Byte 2 0
Byte 1 0 1 0 0 0 0 1 0 14 bit value
Byte 2 0
MS Bits (13...7)
Byte 3 0
LS Bits (6...0)
Byte 1 0 1 0 0 0 0 1 1 21 bit value
Byte 2 0
MS Bits (20...14)
Byte 3 0
MID Bits (13...7)
Byte 4 0
LS Bits (6...0)
= Value
. 70...7F as byte 1 are reserved for special single byte codes.
