AGLAS Master Control Device
Technical Specifications
© ADB SAFEGATE All Rights Reserved
28
96A0480 Rev. B
2.8.1 Circuit Specifications
Cable type L-824 is recommended, for example FLYCY or equivalent. The following parameters (*) represent the specific
characteristic needed in an equivalent L-824 cable. Reuse of existing installations and layout with maximum cable length or
number of lights to be verified.
1
* Contact ADB Safegate for support
2
** Technical requirement, not excluding ICAO /FAA compliance
Cable type (specification) L-824
Capacity of the cable <165 nF/km *
Inductance of the cable <0.20 mH/km *
typical impedance (125 kHz) 35 Ohm
Attenuation of the signal at 125 kHz <5.8 dB/km *
Length of serial circuit 20 km roundtrip (12.4 miles)
Insulation resistance of the series circuit against the L-824 50 Megaohms minimum **
Secondary transformer attenuation ≤ 23 dB at 100 kHz *
