ADB L-852D User Manual

L-852A-D, J & K ITCF, F-Range, ICAO LED Taxiway Centerline Light
96A0460 Rev. C
Introduction
© ADB Airfield Solutions All Rights Reserved6
2.2 Introduction
2.2.1 L852A-D, J & K ITCF
2.2.1.1 Compliance with
Standards
FAA: L-852(L) Series AC 150/5345-46 (Current Edition) and the FAA Engineering Brief No.
67. ETL Certified.
ICAO Taxiway Centerline Straight fixture designed according to ICAO Annex 14 Appendix 2.
Fig. A2-13
2.2.1.2 Uses
2.2.1.3 Operating Conditions
• Temperature:
-40°C to +55°C (-40°F to +131°F)
• Altitude: Sea level to 10,000 feet (3000 m)
• Relative Humidity: Up to 100%
2.2.1.4 Packaging
• In cardboard box: 7 x 13 x 13 in (17.8 x 33 x 33 cm)
• Weight with packing: 15.3 lb (6.94 kg)
• Weight without packing: 12.3 lb (5.58 kg)
WARNING
Read installation instructions in their entirety before starting installation.
• Become familiar with the general safety instructions in this section of the
manual before installing, operating, maintaining or repairing this
equipment.
• Read and carefully follow the instructions throughout this manual for
performing specific tasks and working with specific equipment.
Failure to follow these warnings may result in serious injury or
equipment damage.
FAA L-852A(L)
Taxiway centerline on straight sections and clearance bar in category I and
II applications, >
1,200 ft RVR
FAA L-852B(L)
Taxiway centerline on curved sections in category I and II applications,
>1,200 ft RVR
FAA L-852C(L)
Taxiway centerline on straight section and clearance bar in category III
applications,
FAA L-852D(L)
Taxiway centerline on curved sections in category III applications, <1,200
ft RVR
White/white or white/yellow used on MIRL runway edge for intersections
where runway edge spacing >400 ft (122 m)
FAA L-852J(L)
Taxiway centerline on curved sections in category I and II applications,
>
1,200 ft RVR
FAA L-852K(L)
Taxiway centerline on curved sections in category III applications, <1,200
ft RVR
NOTE: Use of two LED modules allows the option of separate control of each module in
bi-directional applications.
