© ADB Airfield Solutions All Rights Reserved 13
2.3.3.2 Safety Considerations Read the installation section of all system component manuals before installing this
equipment. A thorough understanding of system components and their requirements will
promote safe and efficient installation. See FAA AC 150/5340-30, Design and Installation
Details for Airport Visual Aids, and site plans and specifications for field installation of taxiway
in-pavement lights.
2.3.3.3 Unpack the Unit To reduce the possibility of damaging the light assembly, unpack the F-Range components at
the installation site. The F-Range fixtures may be packed in individual boxes; for larger
quantities, up to 36 fixtures may be packed in one box.
To unpack the F-Range fixture, open the box flaps and carefully remove the top packing
material.
If damage to any equipment is noted, file a claim form with the carrier immediately.
2.3.3.4 Coding Review the coding details for the appropriate type of F-Range fixture before installation.
If applicable, verify you have the correct kit for the light fixture you are upgrading.
L-852A, B, C, D, J, K and ICAO Coding are identified in “Parts” on page 43.
NOTE: The triangular arrowhead on the top of the fixture shows the location of the index pin
in the lower cover. The arrowhead pointer does NOT indicate any geographical orientation or
placement.
2.3.3.5 Verify Input
Requirements and Equipment
Needed
The F-Range light fixture is designed for connection to a 6.6A or 20A series lighting circuit via
an L-830 (60 Hz) or L-831 (50 Hz) isolation transformer.
Make sure you have the necessary tools and materials ready for installation (not supplied).
Also consider other tools that might be needed based on site-specific conditions.
Table 1: Suggested Tools and Materials for Installation and Repair
WARNING
Allow only qualified personnel to install ADB Airfield Solutions and auxiliary
equipment. Use only approved equipment. Using unapproved equipment in
an approved system may void FAA approvals. Observe and follow the
safety instructions in this document and all other related documentation.
Make sure all equipment is rated and approved for the environment where
it is being used.
Failure to follow these warnings may result in serious injury or
equipment damage.
Qty. Description Qty. Description
1 Torque wrench
1
Set of screwdrivers, one with 3/8" (9.525mm)
minimum blade width
1 Alignment jig
1 Diamond-faced core drill
As
needed
Silicone grease
1
Diamond-faced saw, 3/8" (9.525mm)
thick
As
needed
Joint sealing filler
1 Crimping tool 1 Pressure test fitting assembly
1 Small water suction pump
As
needed
Dow Corning Molykote
®
3452 or equal
(ADB P/N 67A0095) - used on top cover
prism seal
2
Eyebolts, 3/8 inch (9.525mm)
diameter
1 Lifting rod, 16 inches (406mm) long
As
needed
Novagard
®
Silicone Versilube
®
G322L
™
(ADB P/N 67A0009) - used on O-ring
between top cover and inner pan assembly;
also may be applied to four nipples of inner
pan assembly to install optical assembly
1 or 2 L-830 / L-831 isolation transformer
1 Set of fiber brushes
1
Set of socket wrenches, 1/2"
(12.7mm) drive
