L-852A-D, J & K ITCF, F-Range, ICAO LED Taxiway Centerline Light
96A0460 Rev. C
Part Diagrams and Part Numbers
© ADB Airfield Solutions All Rights Reserved50
4.1.1 ITCF Spare Parts Use the table below to create a sufficiently large stock of spare parts to maintain the IRGL
unit. Consider acquiring approximately 10% spare final assemblies (with a minimum quantity
of 1) for the total amount of equipment in the field. This allows for repairs to be made in the
shop. Components that are more likely to need replacement, such as prisms, should be
stocked at higher quantities, while PCB assemblies should be stocked in smaller quantities. If
you have questions, contact your ADB representative.
Table 5: ITCF Parts
Part No. Description Figure Notes
61A0459 Arctic kit heater, Heater Disc, 2 Leads Figure 30
44A7387-10 Small Pan - cord set Figure 28, Figure 29
4072.42.351 Intermediate Pan cord set 2 Pin 18" Figure 30
70A0329 Cord set terminal, female disconnect Figure 28, Figure 29
48A0444-XXX-XXX LED light engine, L-852A, B, C, J, green Figure 28
48A0443-XXX-XXX LED light engine, L-852D, K, green Figure 28, Figure 30
4072.42.380 AD Light Plug Bracket Figure 30
7080.90.335 O-ring, inner cover seal Figure 32
7080.90.710 O-RING, INPAVE FLASHER TOP INNER COVER Figure 30
63B0267-011 O-ring, pressure release screw Figure 28
60A2602 Pressure release screw Figure 28
63A0979-1 Prism, L-852A, B, and J Figure 32
63A0993-2 Prism, L852C, D, and K Figure 32
4071.50.030 Prism gasket sleeve Figure 32
4071.50.052 Prism keeper plate Figure 32
63A0986 Seal, prism keeper plate Figure 32
54A0022-8060 Thermostat Figure 31
