ADB L-852D User Manual

© ADB Airfield Solutions All Rights Reserved 25
2.4.2.7 Installing Power
Supplies, Heaters, and
Thermostats
Figure 16: Bottom Pan ITCF and ICAO Straight Assembly Cordset
Figure 17: Thermostat and Heater
44A7387-10
F-RANGE CORD SET OVERMOLD
60A3339-1
Bottom Pan 1 CORDSET W/O MONITORING
44A6698/7/2
L-852A, B & C - LED P.S. 300mA W/O MON
# 2 - HEATER
TWO HEATER ONE THERMOSTAT
WIRING CONFIGURATION
USED WITH ITCF/XXX31X CONFIGURATIONS
CONNECTION TO
POWER CORDSET IN BASE
THERMOSTAT
M
F
M
F
F
BASE
PCB
J1BJ1A
MM
# 1 - HEATER
F
M
F
CONNECTION TO J1A
PCB POWER CONN IN BASE
F
M
M
F
CONNECTION TO J1A
PCB POWER CONN IN BASE
F
MM
J1A J1B
PCB
BASE
F
F
M
F
M
THERMOSTAT
CONNECTION TO
POWER CORDSET IN BASE
ONE HEATER ONE THERMOSTAT
WIRING CONFIGURATION
USED WITH ITCF/A THRU C & J, BI-DIR. 2-CORD
# 1 - HEATER
INSTALLED
ON HTR
INSTALLED
ON HTR
INSTALLED
ON HTR
INSTALLED
ON HTR
LINES ARE FOR
REFERENCE ONLY
AS A GUIDE TO
CONNECTION PATH
LINES ARE FOR
REFERENCE ONLY
AS A GUIDE TO
CONNECTION PATH
