ADB L-852D User Manual

L-852A-D, J & K ITCF, F-Range, ICAO LED Taxiway Centerline Light
96A0460 Rev. C
Introduction
© ADB Airfield Solutions All Rights Reserved8
Figure 1: View of LED In-Pavement ITCF Light Fixture (Typical Configuration)
2.2.2.1 Inner Pan Subassembly The inner cover assembly includes the inner cover, L-823 cord sets, and the power supply, as
shown in Figure 1.
2.2.2.2 Optical Unit L852A, B,
C, J and ICAO Straight
Figure 2: Optical Unit 48A0444-XXX-XXX for L852A, B, C, J and ICAO Straight
2.2.2.3 Optical Unit L852D & K Figure 3: Optical Unit 48A0443-XXX-XXX for L852D and K
48A0444/ X X X
G R N = Green
Y L W = Amber
W H T = WHITE
R E D = RED
48A0443/ X X X
G R N = Green
Y L W = Yellow
