9. INSTALLATION OF RIGID WASHING MACHINES (GROUPS B-C)
EWR-25
EWR-30
EWR-40
EWR-60
Static floor load (kN - lb)
2,08 - 468
2,25 - 506
2,46 - 553
3,2 - 678
Dinamic floor load (Kn - lb)
0,5 - 112
0,6 - 135
0,9 - 202
1 - 225
Maximum vertical load (kN - lb)
2,58 - 580
2,85 - 641
3,36 - 755
4,2 - 944
Dinamic load frequency (Hz)
12
12
12
12
G factor
200
200
200
200
EWS-25
EWS-30
EWS-40
EWS-60
EWS-80
Static floor load (kN - lb)
2,17 - 478
2,39 - 526
2,81 - 619
3,40 - 749
4,73 - 1042
Dinamic floor load (Kn - lb)
0,3 - 66
0,35 - 77
0,45 - 99
0,6 - 132
0,8 - 176
Maximum vertical load (kN - lb)
2,47 - 538
2,74 - 603
3,26 - 718
4 - 881
5,53 - 1218
Dinamic load frequency (Hz)
12
12
12
12
12
G factor
100
100
100
100
100
Forces transmitted by the washing machine
WARNING! Rigid washing machines must not be installed on non-foundation floors without authorisation
from a technician familiar with the structure and resistance of the building.
Please check the weight of the machine plus the dynamic forces generated during spinning. The
manufacturer does not accept responsibility for any damage due to vibration in this type of installation.
The anchorage base IS SOLD SEPARATELY.
WARNING! RIGID MACHINES MUST BE ANCHORED TO THE FLOOR. Correct construction of the anchorage
to the floor is essential to ensure the correct working of the appliance and to prevent serious damage to the
structure of the machine
