28 American Dryer Corp. 450269-2
If the help menu feature “CODE” is selected, the center section will present “Help Codes” and “Events”. All of the
items in the code menu will automatically scroll up and continue to scroll until LOW/DOWN ARROW key is pressed
to select a new help menu feature.
All CODES starting with an “H” represent some condition that could interfere with the proper functioning of the dryer.
There could be up to 3 “H” codes listed within the HELP MENU.
• H1 represents the last failure recorded.
• H2 represents the second to last failure recorded.
• H3 represents the third to last failure recorded.
Each Help Code will be followed by a two digit code. This two digit code will reflect a particular issue.
HELP
CODE
CODE DESCRIPTION
81 Lower Exhaust Probe Fault
86 Upper Exhaust Probe Fault
87 Upper Axial Probe Fault
82 Lower Axial Probe Fault
89 Upper Sail Switch Open Fault
88 Upper Sail Switch Closed Fault
84 Lower Sail Switch Open Fault
83 Lower Sail Switch Closed Fault
90 Upper Rotation Sensor Fault
91 Lower Rotation Sensor Fault
92 Gen 2 Card Reader Communication Fault
E1 Top Radiant Sensor fault count
E2 Top Burner Ignitor fault count
E3 Top Exhaust High Limit
E4 Bottom Radiant sensor fault count
E5 Bottom Burner Ignitor fault count
E6 Bottom Exhaust High Limit
E7 Coin 1 Bad Coin count
E8 Coin 2 Bad Coin Count
E9 Upper pocket forward rotation sensor fault count
EA Upper pocket reverse rotation sensor fault count
EB Lower pocket forward rotation sensor fault count
EC Lower pocket reverse rotation sensor fault count
ED S.A.F.E. DISABLED – Water not connected
