add-e NEXT - Setting Lower Stop; Attaching the Remote Control

Seite 20
The handlebar remote control can be
attached optionally. For function and
operation, see the user manual in the
chapter: "add-e NEXT Remote Control".
add-e NEXT remote control
Unscrew the setting screw for the
lower stop (3) as far as possible without
the screw touching the swing arm in a
disengaged state.
Screw just does not touch the swingarm
5. Setting Lower Stop
The setting screw for the lower stop (3) prevents the motor from swinging back
and forth unintentionally when riding over bumps.
6. Attaching the add-e NEXT Remote Control
The remote control provides an alternative to using the power setting knob on the
battery to operate the add-e NEXT. This allows the battery to be installed in hard-
to-reach places.
CongraTulaTIons!
The add-e nexT has been InsTalled
suCCessfully!
