IRIS-4 Technical Reference Manual.docx 12/01/2023 page 41
6.13.5.4 Default CID Set/Restore event codes
6.14 Relays
This option lets you configure the relays.
Relay input follower
This feature lets the terminal relay outputs be set to follow a pin input, with a
delay if required. Normally a relay will open if the associated input goes open
circuit, and vice-versa, but this can be inverted if required.
Note: Do not use this feature for a relay with another purpose, e.g., communications path trouble reporting.
Relay SMS activation
The terminal lets each relay be activated or deactivated with a predefined SMS
message from a mobile phone.
6.14.2.1 Phone number
This option sets which calling device (mobile phone) may control the relay with
the relevant SMS message. This is done by using the Calling Line Number (CLI)
on the SMS and comparing this with the number entered.
Pin no.
CID event
code
Group
no.
Zone
no.
CID event description
1 110 00 001 Fire alarm zone 1
2 120 00 002 Panic alarm zone 2
3 130 00 003 Burglary alarm zone 3
4 400 00 004 Open/Close zone 4
5 300 00 005 System Trouble zone 5
6 573 00 006 Burglary bypass zone 6
7 139 00 007 Intrusion verifier zone 7
8 137 00 008 Tamper alarm zone 8
9 301 00 009 AC Power trouble zone 9
10 380 00 010 Sensor trouble zone 10
11 101
00
011 Personal emergency alarm
zone 11
12 302 00 012 Low system battery zone 12
13 100 00 013 Medical alarm zone 13
14 323 00 014 Alarm relay zone 14
15 323 00 015 Alarm relay zone 15
16 323 00 016 Alarm relay zone 16
