ADEEPT ADA031 - Assembly and Wiring; Base Assembly

www.adeept.com
21
Assemble the following components
Effect diagram after assembling
Assemble the following components
Effect diagram after assembling
4. Assembly
4.1. Pedestal Assembly.
1. Connect the Adeept Touch Button to 3-Pin Wire.
2. Connect the OLED to 4-Pin Wire.
For convenience to read, 3-Pin Wire will be only
shown the connector part in the following section.
OLED x1
4-Pin Wire x1
For convenience to read, 4-Pin Wire will be only
shown the connector part in the following section.
Adeept Touch Button x1
3-Pin Wire x1
