27
Assemble the following components
Effect diagram after assembling
8.Fix 18650x2 Battery Holder to A01.
M3*10 Countersunk
Head Screw x2
18650x2 Battery
Holder x1
M3 Nut x2
The wires of 18650x2
Battery Holder are
near outside.
