Effect diagram after assembling
2. Fix A06 to Raspberry Pi.
Assemble the following components
For continence to read, the acrylic
sheets in the document are
available in a variety of colors. The
color of them is subject to actual
conditions, and their number is
differentiated by shape.
M2.5x4+6 Copper
Standoff x4
A06 x1
