2.4. Body part assembly.
1. Fix two Car Lights on A07.
2. Fix two Car Lights on the other A07.
M1.4*6 Self-tapping Screw x4
The end already connected
with wire of the Car Light
faces to the left. Pay attention
to the relative position of
each part, do not install in a
wrong way.
Effect diagram after assembling
Defined as Car Light-A x2
M1.4*6 Self-tapping
Screw x4
Note that the relative
position of each part is
different from the
previous step. The end
already connected with
wire of the Car Light
faces to the right.
