Assemble the following components
3. Connect the Car Light as shown below.
4. Fix S12D3 Coupling on GA12-N20 Gear Motor (2 sets).
GA12-N20 Gear
Motor x1
Effect diagram after assembling
M4x4 Locking Screw x2
S12D3 Coupling x1
The distance here should not be too
short, and should be kept at a
distance of 3-4mm.
Effect diagram after assembling
