2.3. Rocker arm assembly.
1. Take two rocker arms as in the illustration and connect them to A18.
2.Fix a debugged servo to A17.
Effect diagram after assembling
Assemble the following components
At this time, the rocker arm hasn’t been
fixed. When fixing, the mounting hole
of the rocker arm should be aligned
with the round hole on the A07.
Self-tapping screw packaged
with servo x2
Effect diagram after assembling
Assemble the following components
To Next Page
