CHARACTERISTICS:
The HD67610-A1 is a PROFINET / J1939 Converter.
It has the following characteristics:
Up to 512 bytes in reading and 512 bytes in writing;
Triple isolation between CAN - Power Supply, CAN - Ethernet, Power Supply - Ethernet.
Two-directional information between J1939 bus and PROFINET bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8…24V AC or 12…35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67610 software on your PC in order to perform the following:
Define the parameter of PROFINET line;
Define the parameter of CAN line;
Define the J1939 frames that the Converter can accept;
Define the J1939 frames that the Converter sends trough the J1939 line;
Update the device.
