The Dotz Par RF remote (sold separately) has many different func-
tions and allows you to control your Dotz Par from long distance. The
remote can control your system up to 25 meters. To use the remote
you must first activate the fixtures receiver, to activate the receiver
please see the instructions on page 9.
BLACKOUT - Pressing this button will blackout the fixture.
FADE - This button will activate the fade program.
COLOR - This button will activate the static color mode. Use the “+”
and “-” buttons to scroll through the colors and find your desired
color.
PROGRAMS - This button will activate the built-in programs mode.
Use the “+” and “-” buttons to scroll through the 7 programs and find
your desired program.
SOUND ACTIVE - This button activates sound active mode.
AUTO RUN - When in program mode, press this button and use the
“+” and “-” buttons to adjust the speed of the built-in programs. You
can also use this button to activate program mode.
“+” and “-” - Use these buttons to adjust the speed of the built-in
program, scroll through the built-in programs, and scroll through the
static colors.
5P Hex Dotz Par RF Operation
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 WHITE
0 - 255 0% - 100%
5 AMBER
0 - 255 0% - 100%
6 UV
0 - 255 0% - 100%
5P Hex 6 Channel - DMX Values & Functions
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 WHITE
0 - 255 0% - 100%
5 AMBER
0 - 255 0% - 100%
6 UV
0 - 255 0% - 100%
7 MASTER DIMMER
0 - 255 0% - 100%
5P Hex 7 Channel - DMX Values & Functions
