ADJ 5P HEX - DMX Channel Functions Reference; 8 and 12 Channel DMX Values

ADJ Products, LLC - www.adj.com - 5P Hex User Manual Page 15ADJ Products, LLC - www.adj.com - 5P Hex User Manual Page 14
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 WHITE
0 - 255 0% - 100%
5 AMBER
0 - 255 0% - 100%
6 UV
0 - 255 0% - 100%
7 MASTER DIMMER
0 - 255 0% - 100%
8 STROBING
0 - 31 LED OFF
32 - 63 LED ON
64 - 95 STROBING SLOW - FAST
96 - 127 LED ON
128 - 159 PULSE STROBING SLOW - FAST
160 - 191 LED ON
192 - 223 RANDOM STROBE SLOW - FAST
224 - 255 LED ON
5P Hex 8 Channel - DMX Values & Functions 5P Hex 12 Channel - DMX Values & Functions
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 WHITE
0 - 255 0% - 100%
5 AMBER
0 - 255 0% - 100%
6 UV
0 - 255 0% - 100%
7 MASTER DIMMER
0 - 255 0% - 100%
8 STROBING
0 - 31 LED OFF
32 - 63 LED ON
64 - 95 STROBING SLOW - FAST
96 - 127 LED ON
128 - 159 PULSE STROBING SLOW - FAST
160 - 191 LED ON
192 - 223 RANDOM STROBE SLOW - FAST
224 - 255 LED ON
9 0 - 255 COLOR MACRO
Please refer to page 22 for macro chart
10 PROGRAMS
0 - 20 NO PROGRAM
21 - 40 30 COLOR CHANGE
41 - 60 6 COLOR CHANGE
61 - 80 COLOR FADE
81 - 100 SOUND ACTIVE 30 COLOR CHANGE
101 - 120 SOUND ACTIVE 6 COLOR CHANGE
121 - 140 SOUND ACTIVE 6 COLOR FADE
141 - 255 NO PROGRAM
