ADJ Products, LLC - www.adj.com - 5P Hex User Manual Page 17ADJ Products, LLC - www.adj.com - 5P Hex User Manual Page 16
5P Hex 12 Channel - DMX Values & Functions
Channel Value Function
11 PROGRAM SPEED/SOUND SENSITIVE
0 - 255 SLOW - FAST
0 - 255 LEAST SENSITIVE - MOST SENSITIVE
12 DIMMER MODE
0 - 20 STANDARD
21 - 40 STAGE
41 - 60 TV
61 - 80 ARCHITECTURAL
81 - 100 THEATRE
101 - 255 DEFAULT DIMMER SETTING
When Channel 10 is between the values of 21-80, Channel 11 will control the
color change speed and color fade speed.
When Channel 10 is between the values of 81-140, Channel 11 will control the
sound sensitivity.
5P Hex Color Macro Chart
0-3=Off 64-67=B+W 128-131=G+B+W 192-195=R+B+W+A 4-7=Red 68-71=B+A 132-135=G+B+A 196-199=R+B+W+UV 8-11=Green 72-75=B+UV 136-139=G+B+UV 200-203=R+B+A+UV 12-15=Blue 76-79=W+A 140-143=G+W+A 204-207=R+W+A+UV 16-19=White 80-83=W+UV 144-147=G+W+UV 208-211=G+B+W+A 20-23=Amber 84-87=A+UV 148-151=G+A+UV 212-215=G+B+W+UV 24-27=UV 88-91=R+G+B 152-155=B+W+A 216-219=G+B+A+UV 28-31=R+G 92-95=R+G+W 156-159=B+W+UV 220-223=G+W+A+UV 32-35=R+B 96-99=R+G+A 160-163=B+A+UV 224-227=B+W+A+UV 36-39=R+W 100-103=R+G+UV 164-167=W+A+UV 228-231=R+G+B+W+A 40-43=R+A 104-107=R+B+W 168-171=R+G+B+W 232-235=R+G+B+W+UV 44-47=R+UV 108-111=R+B+A 172-175=R+G+B+A 236-239=R+G+B+A+UV 48-51=G+B 112-115=R+B+UV 176-179=R+G+B+UV 240-243=R+G+W+A+UV 52-55=G+W 116-119=R+W+A 180-183=R+G+W+A 244-247=R+B+W+A=UV 56-59=G+A 120-123=R+W+UV 184-187=R+G+W+UV 248-251=G+B+W+A+UV 60-63=G+UV 124-127=R+A+UV 188-191=R+G+A+UV 252-255=R+G+B+W+A+UV
