ADJ Products, LLC - www.adj.com - DMX Operator User Manual Page 10
DMX Operator Programming Scenes
1. PRESS AND HOLD PROGRAM BUTTON DOWN (6) for three (3) seconds to activate program
mode. The LCD DISPLAY (3) will indicate the controller is in program mode by displaying
a continuous fast blinking light next to ‘PROG.
2. Select a fixture to program by pressing any or all FIXTURE BUTTONS 1 TO 12 (1).
3. Adjust the faders to the desired fixture settings (i.e. Color, Gobo, Pan, Tilt, Speed, etc.), by
adjusting the fader values from 0-255. Use the PAGE A, B BUTTON (14) if your fixture has
more than eight channels. When switching from Page A to B, you have to move faders to
activate channels.
4. Once the desired fixture settings have been made, press the selected FIXTURE BUTTON (1)
to stop the adjustment of that fixture. Press another FIXTURE BUTTON (1) to select
another fixture to adjust. Make adjustments to multiple fixtures at the same time by selecting
multiple FIXTURE BUTTONS (1) at a time.
5. Repeat steps 2 and 3 until all the fixture settings are complete.
6. When the entire scene is set, press and release the MIDI / REC BUTTON (7) .
8. Press a SCENE BUTTON 1-8 (2) to store this scene. ALL LEDS BLINK 3 TIMES and the LCD
will display the bank and scene where the scene was stored.
9. Repeat steps 2-8 to record the first 8 scenes.
You can copy the settings from one fixture button to another in case you want to add more
lights to your show. Just press and hold the fixture button you want to copy then press the
fixture button you want to copy to.
10. Use the UP and DOWN BANK BUTTONS (4) to record more banks of scenes. There are a
total of 30 banks you can store up to 8 scenes per a bank for a total of 240 scenes.
11. To exit Program Mode press and hold the PROGRAM BUTTON (6) for three seconds. When
exiting Program Mode the Blackout LED is on, to de-activate blackout press the BLACKOUT
BUTTON (10).
