ADJ Dotz Par - Universal DMX Control; Primary-Secondary Configuration

Dotz Par System Menu
ADJ Products, LLC - www.adj.com - Dotz Par User Manual Page 9
color.
1. Plug the fixture in and press the MODE button until “Manual
Dimmer” is displayed, and press ENTER.
2. When “r.XXX” is displayed you are in Red dimming mode.
Press the UP and DOWN buttons to adjust intensity.
3. When “G.XXX” is displayed you are in Green dimming mode.
Press the UP and DOWN buttons to adjust intensity.
4. When “b.XXX” is displayed you are in Blue dimming mode.
Press the UP and DOWN buttons to adjust intensity.
Color Macro - Select your desired color macro to remain
static.
1. Press the MODE button until “C-XX” is displayed. “XX” repre-
sents the current displayed macro number.
2. Use the UP and DOWN button to scroll through the 35 color
macros until you nd your desired color.
Built-In Programs - Select your desired Built-In pro-
gram.
1. Press the MODE button until “P-XX” is displayed. “XX” rep-
resents the current displayed program number. Use the UP and
DOWN buttons to scroll through 7 dierent programs.
2. Press ENTER to move through the various adjustments of each
program, and use the UP and DOWN buttons to make adjust-
ments.
Sound Mode - In this mode the unit will run in sound
active mode.
1. Press the MODE button until “Sound Mode” is displayed.
ADJ Products, LLC - www.adj.com - Dotz Par User Manual Page 14
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 0 - 255 MASTER DIMMER 0% - 100%
5 COLOR MACROS
0 OFF
1 - 7 BASTARD AMBER
8 - 15 MEDIUM AMBER
16 - 23 PALE AMBER GOLD
24 - 31 GALLO GOLD
32 - 39 GOLDEN AMBER
40 - 47 LIGHT RED
48 - 55 MEDIUM RED
56 - 63 MEDIUM PINK
64 - 71 BROADWAY PINK
72 - 79 FOLLIES PINK
80 - 87 LIGHT LAVENDER
88 - 95 SPECIAL LAVENDER
96 - 103 LAVENDER
104 - 111 INDIGO
112 - 119 HEMSLEY BLUE
120 - 127 TIPTON BLUE
128 - 135 LIGHT STEEL BLUE
136 - 143 LIGHT SKY BLUE
144 - 151 SKY BLUE
152 - 159 BRILLIANT BLUE
160 - 167 LIGHT GREEN BLUE
168 - 175 BRIGHT BLUE
176 - 183 PRIMARY BLUE
184 - 191 CONGO BLUE
192 - 199 PALE YELLOW GREEN
Dotz Par 9 Channel Mode
