Flat Par TW5 Power Cord Daisy Chain
ADJ Products, LLC - www.adj.com - Flat Par TW5 User Manual Page 22
With this feature you can connect the xtures to one another using the IEC input and output
sockets. The maximum quantity that can be connected is 25 xtures. After 25 xtures you will
need to use a new power outlet. Fixtures must be of the same make and model. DO NOT mix
xtures.
Flat Par TW5 Fuse Replacement
Disconnect the unit from its power source. Remove the power cord from the unit. Once the cord has
been removed, locate the fuse holder inside the power socket. Insert a at-head screw driver into
the power socket and gently pry out the fuse holder. Remove the bad fuse and replace with a new
one. Note that the fuse holder also contains a holder for a spare fuse.
Flat Par TW5 Trouble Shooting
Listed below are a few common problems the user may encounter, with solutions.
Unit not responding to DMX:
Check that the DMX cables are connected and wired correctly (pin 3 is ‘hot’; on some other DMX
devices pin 2 may be ‘hot’). Also, check that all cables are connected to the right connectors. THe
way in which the cables are connected can aect how the device operates.
Unit does not respond to sound:
1. Quiet or high pitched sounds will not activate the unit.
2. Make sure that Sound Active mode is activated.
Flat Par TW5 Cleaning
Due to fog residue, smoke, and dust, cleaning of the internal and external optical lenses must be
carried out periodically to optimize light output.
1. Use normal glass cleaner and a soft cloth to wipe down the outside casing.
2. Clean the external optics with glass cleaner and a soft cloth every 20 days.
3. Always be sure to dry all parts completely before plugging the unit back in.
Cleaning frequency depends on the environment in which the xture operates (i.e. smoke, fog resi-
due, dust, dew).
