ADJ FLAT PAR TW5 - Remote Control Functions

Flat Par TW5 ADJ LED RC3 Operation
ADJ Products, LLC - www.adj.com - Flat Par TW5 User Manual Page 12
The ADJ LED RC3 infrared remote (sold seperately) gives you complete control of your xture. For
best results, the controller must be aimed at the front of the xture and be within the maximum oper-
ating range of 30 feet. To use the ADJ LED RC3, you must rst activate the xture’s infrared receiver,
as shown in the Operating Instructions section of this manual.
BLACKOUT - Pressing this button will blackout the xture.
AUTO RUN - Pressing this button will cycle through the auto run mode, color fade mode, and color
change. You can control the speed of the 3 modes by pressing the SPEED button rst, then pressing
the “+” and “-” buttons. In color fade and color change mode, press the “+” and “-” buttons to scroll
through the 8 modes.
PROGRAM SELECTION - Pressing this button activates static color mode. Use the “+” or “-” to
scroll through the 32 colors. Press Flash to activate/deactivate strobing. Use the “+” and “-” buttons
to adjust the strobe speed.
DMX MODE - Press this button to cycle between DMX Channel mode selection, DMX addressing,
DMX State, and dimming curve selection. Each press of this button will change to the next mode.
• In DMX State mode, press the the “+” and “-” buttons to scroll through the DMX state modes.
See the Operating Instructions section of this manual for detailed information.
• In DMX address mode, press the the “+” and “-” buttons to adjust the DMX address.
• In dimmer curve mode, press the the “+” and “-” buttons to scroll through the dimmer curves.
See the Operating Instructions section of this manual for detailed information.
• In DMX Channel selection, press the the “+” and “-” buttons to scroll through the dierent DMX
Channel modes. See the Operating Instructions section of this manual for detailed informa-
tion. The xture’s LEDs will glow in dierent colors to signify the selected DMX Channel Mode, as
described in the table below:
LED COLOR DMX CHANNEL MODE
Warm White 2 Channel Mode
Cool White 3 Channel Mode
Amber 4 Channel Mode
Warm White & Cool White 5 Channel Mode
Warm White & Amber 8 Channel Mode
Cool White & Amber 9 Channel Mode
SOUND ACTIVE - This button activates sound active mode. Use the “+” and “-” buttons to scroll
through the 8 sound active modes. Press the Speed button and use the “+” and “-” buttons to ad-
just the sound sensitivity level.
SECd - This designates the xture as a secondary xture in a primary/secondary conguration.
