ADJ FOCUS BEAM LED - DMX Traits: Channel Functions & Values

24
16 Channels 18 Channels Values Functions
1 1 000-255
PAN MOVEMENT 8-BIT:
Pan Movement (0° - 630°)
2 000-255
PAN FINE 16-BIT:
Fine Control of Pan Movement
2 3 000-255
TILT MOVEMENT 8-BIT:
Tilt Movement (0° - 270°)
4 000-255
TILT FINE 16-BIT:
Fine Control of Tilt Movement
3 5
COLOR WHEEL:
000-004 Open / White
005-011 White + Red
012-018 Red
019-025 Red + Light Blue
026-032 Light Blue
033-039 Light Blue + Green
040-046 Green
047-053 Green + Yellow
054-060 Yellow
061-067 Yellow + Orange
068-074 Orange
075-081 Orange + Magenta
082-088 Magenta
089-095 Magenta + Amber
096-102 Amber
103-109 Amber + Lime
110-116 Lime
117-123 Lime + Purple
124-130 Purple
131-137 Purple + Pink
138-144 Pink
145-151 Pink + Cyan
152-158 Cyan
159-165 Cyan + CTO
166-172 CTO
173-179 CTO + Blue
180-186 Blue
187-193 Blue + White
194-220 Clockwise Rotation Fast - Slow
221-229 Stop
230-255 Counter-Clockwise Rotation Slow - Fast
DMX TRAITS: CHANNEL FUNCTIONS & VALUES (16/18 DMX Channels)
