32
DMX TRAITS
CHANNEL
VALUES FUNCTION
36-CH 40-CH 51-CH
33 36 47
Frame Macros (continued, see Frame Macros Chart for
details)
232 - 239 Macro29
240 - 247 Macro30
248 - 255 Macro31
34 37 48
Dim Modes
000 - 020 Standard
021 - 040 Stage
041 - 060 TV
061 - 080 Architectural
081 - 100 Theatre
101 - 120 Stage 2
121 - 140 Dim Speed, fast to slow, 0.1s to 10s
141 - 255 Default
38 49
Dim Curves
000 - 020 Linear
021 - 040 Square
041 - 060 Inv. Squa
061 - 080 S. Curve
081 - 255 No Function
35 39 50 000 - 255
Pan/Tilt Speed, maximum to minimum speed
36 40 51
Special Functions, Reset, & Internal Programs
000 - 005 No function
006 - 010 Normal operation, default refresh rate = 1200 Hz
011 900 Hz
012 910 Hz
013 920 Hz
014 930 Hz
015 940 Hz
016 950 Hz
017 960 Hz
CONTINUED ON NEXT PAGE
