ADJ FOCUS PROFILE - DMX Traits: Pan, Tilt, Color, CTO, and Presets; Pan, Tilt, and Fine Control Channels; Color Mixing, CTO, and Color Wheel Functions; White Color Temperature Presets

26
CHANNEL
VALUES FUNCTION
36-CH 40-CH 51-CH
1 1 1 000 - 255
Pan Movement, 630/540
2 2 000 - 255
Pan Fine
2 3 3 000 - 255
Tilt Movement
4 4 000 - 255
Tilt Fine
3 5 5 000 - 255
Cyan
6 000 - 255
Cyan Fine
4 6 7 000 - 255
Magenta
8 000 - 255
Magenta Fine
5 7 9 000 - 255
Yellow
10 000 - 255
Yellow Fine
6 8 11 000 - 255
CTO
12 000 - 255
CTO Fine
7 9 13
White Color Temperature Presets
000 - 023 Open
024 - 069
See White Color Temperature Presets section
070 - 255 6700K
8 10 14
Color Wheel
000 - 005 Color off (open)
006 - 011 Red
012 - 017 Blue
018 - 023 Green
024 - 029 Yellow
030 - 035 CRI
035 - 041 CTB
042 - 047 Color off (open)
048 - 059 Open - Red
060 Red
061 - 070 Red - Blue
071 Blue
072 - 081 Blue - Green
CONTINUED ON NEXT PAGE
DMX TRAITS
