ADJ FOCUS PROFILE - DMX Traits: Color Wheel Rotation and Rotating Gobos; Color Wheel Rotation and Effects; Rotating Gobo Selection and Shake Effects

27
DMX TRAITS
CHANNEL
VALUES FUNCTION
36-CH 40-CH 51-CH
8 10 14
Color Wheel (continued)
082 Green
083 - 092 Green - Yellow
093 Yellow
094 - 104 Yellow - CRI
105 CRI
106 - 116 CRI - CTB
117 CTB
118 - 126 CTB - Open
127 Color off (open)
128 - 190 Clockwise color wheel rotation, fast to slow
191 - 192 Stop color wheel rotation
193 - 255 Counter-clockwise color wheel rotation, slow to fast
9 11 15
Rotating Gobos, continuous rotation
000 - 006 Open
007 - 013 Gobo 1
014 - 020 Gobo 2
021 - 027 Gobo 3
028 - 034 Gobo 4
035 - 041 Gobo 5
042 - 048 Gobo 6
049 - 055 Gobo 7
056 - 062 Gobo 1 shake, slow to fast
063 - 069 Gobo 2 shake, slow to fast
070 - 076 Gobo 3 shake, slow to fast
077 - 083 Gobo 4 shake, slow to fast
084 - 090 Gobo 5 shake, slow to fast
091 - 097 Gobo 6 shake, slow to fast
098 - 104 Gobo 7 shake, slow to fast
CONTINUED ON NEXT PAGE
