ADJ FOCUS PROFILE - DMX Traits: Rotating Gobo Rotation and Fixed Gobos; Rotating Gobo Wheel Rotation and Indexing; Fixed Gobo Selection and Rotation

28
DMX TRAITS
CHANNEL
VALUES FUNCTION
36-CH 40-CH 51-CH
9 11 15
Rotating Gobos, continuous rotation (continued)
105 - 178 Clockwise gobo wheel rotation, fast to slow
179 - 181 Stop gobo wheel rotation
182 - 255 Counter-clockwise gobo wheel rotation, slow to fast
10 12 16
Gobo Rotation
000 - 127 Gobo Rotation Indexing
128 - 190 Clockwise Gobo Rotation, fast to slow
191 - 192 Stop Gobo Rotation
193 - 255 Counter-clockwise Gobo Rotation, slow to fast
17 000 - 255
GoboRotationIndexing,Fine
11 13 18
FixedGobos,continuous rotation
000 - 006 Open
007 - 013 Gobo 1
014 - 020 Gobo 2
021 - 027 Gobo 3
028 - 034 Gobo 4
035 - 041 Gobo 5
042 - 048 Gobo 6
049 - 055 Gobo 7
056 - 062 Gobo 8
063 - 069 Gobo 1 shake, slow to fast
070 - 076 Gobo 2 shake, slow to fast
077 - 083 Gobo 3 shake, slow to fast
084 - 090 Gobo 4 shake, slow to fast
091 - 097 Gobo 5 shake, slow to fast
098 - 104 Gobo 6 shake, slow to fast
105 - 111 Gobo 7 shake, slow to fast
112 - 118 Gobo 8 shake, slow to fast
119 - 185 Clockwise fixed gobo wheel rotation, fast to slow
186 - 188 Stop fixed gobo wheel rotation
189 - 255 Counter-clockwise fixed gobo wheel rotation, slow to fast
CONTINUED ON NEXT PAGE
