ADJ FOCUS PROFILE - DMX Traits: Shutter, Dimmer, and Prisms; Shutter and Strobe Functionality; Dimmer Intensity and Fine Control; Prism 1 and Prism 2 Effects

29
DMX TRAITS
CHANNEL
VALUES FUNCTION
36-CH 40-CH 51-CH
12 14 19
Shutter, Strobe
000 - 031 No function (shutter closed)
032 - 063 No action, shutter open
064 - 095 Strobe, slow to fast
096 - 127 No action, shutter open
128 - 159 Pulse effect, slow to fast
160 - 191 No action, shutter open
192 - 223 Random strobe, slow to fast
224 - 255 No action, shutter open
13 15 20 000 - 255
Dimmer Intensity, 0% to 100%
16 21 000 - 255
Dimmer Fine, 0% to 100%
14 17 22
Prism 1
000 - 031 No effect
032 - 255 Prism 1 (3 facet)
15 18 23
Prism 1 Rotation
000 - 127 Prism 1 indexing
128 - 189 Clockwise rotation, fast to slow
190 - 193 No rotation
194 - 255 Counter-clockwise rotation, slow to fast
24 000 - 255
Prism1IndexFine
16 19 25
Prism 2
000 - 031 No effect
032 - 255 Prism 2 (4-facet)
17 20 26
Prism 2 Rotation
000 - 127 Prism 2 indexing
128 - 189 Clockwise rotation, fast to slow
190 - 193 No rotation
194 - 255 Counter-clockwise rotation, slow to fast
27 000 - 255
Prism2IndexFine
18 21 28 000 - 255
Focus, continuous adjustment, far to near
29 000 - 255
Focus Fine
