30
DMX TRAITS
CHANNEL
VALUES FUNCTION
36-CH 40-CH 51-CH
19 22 30 000 - 255
Zoom, minimum to maximum beam angle
31 000 - 255
Zoom Fine
20 23 32
Iris
000 - 191 Diameter, maximum to minimum
192 - 223 Pulse opening, fast to slow
224 - 255 Pulse closing, slow to fast
33 000 - 255
Iris Fine
21 24 34 000 - 255
Frost, open to full frost
22 25 35
AnimationIndexingandRotation
000 - 005 Open
006 - 127 Animation indexing
128 - 189 Clockwise animation rotation, fast to slow
190 - 193 No rotation
194 - 255 Counter-clockwise animation rotation, slow to fast
23 26 36 000 - 255
Blade 1A, 0% to 100%
24 27 37 000 - 255
Blade 1B, 0% to 100%
25 28 38 000 - 255
Blade 2A, 0% to 100%
26 29 39 000 - 255
Blade 2B, 0% to 100%
27 30 40 000 - 255
Blade 3A, 0% to 100%
28 31 41 000 - 255
Blade 3B, 0% to 100%
29 32 42 000 - 255
Blade 4A, 0% to 100%
30 33 43 000 - 255
Blade 4B, 0% to 100%
31 34 44
Frame Rotation
000 - 126 Minimum (-60 degrees)
127 - 128 Parallel (0 degrees)
129 - 255 Maximum (+60 degrees)
45 000 - 255
Frame Rotation Fine
32 35 46 000 - 255
Frame Speed, maximum to minimum
CONTINUED ON NEXT PAGE
