ADJ Products, LLC - www.adj.com - Jolt 300 User Manual Page 22
Jolt 300 Pixel Zone Control
This xture features pixel zone control. See the diagram below, which illustrates the specic pixel
zone set up.
1 2 3
DISPLAY SERVICE PORT
