ADJ JOLT 300 - Overview

ADJ Products, LLC - www.adj.com - Jolt 300 User Manual Page 6
Jolt 300 Overview
1. Locking 3/5-Pin XLR Connectors In
2. Safety Cable Attachment Point
3. Locking Power Connector In
4. Omega Bracket
5. Locking Power Connector Out
6. Locking 3/5-Pin XLR Connectors Out
1 2
9 10
3 5 6
7 8 11 12
4
7. Service Port
8. MENU Button
9. SETUP Button
10. UP Button
11. DOWN Button
12. Display
